USB 3.0 Type A Female

Material

Insulator : UL94V-0 Blue
Contact : Copper Alloy
Shell : SPCC
RoHS compliant

Specifcation

Contact Resistance: 30 Ω Max.
Insulator Resistance: 100 Megohoms Min.
Current Rating: 1.5 AMP Min.
Environmental: -55℃ to +105℃
Dielectric Withstanding Vol.: 500Vac Min.

Voltage : 30VAC(R.M.S)

How to order

  • Series No.

    A30

    USB 3.0

  • Type

    F

    Female

  • No. of Pin

    9

    9pin

  • Type

    M

    M:SMT
    M1: 180 SMT
    R: Right Angle
    S: Straight

  • Contacts Plating

    G

    G: Gold Flash
    G3: Gold 3u"
    G5: Gold 5u"
    G10: Gold 10u"
    G15: Gold 15u"...

  • Color

    Blank : Blue
    Black : B
